MagPure Plasmid Mini Kit

Introduction The MagPure Plasmid purification system uses the paramagnetic bead technology for high-throughput preparation of high-copy or low-copy plasmid DNA from E. coli cells. This kit also can be used with fosmid and BAC vector-based constructs. The system uses alkaline lysis followed by a MagPure purification to differentially bind plasmid DNA to paramagnetic beads. While the DNA is bound to the beads, contaminants can be rinsed away using a simple washing procedure. Because MagPure uses magnetic separation technology, the protocol does not require vacuum filtration. This makes kit extremely amenable to automation. Plasmid DNA purified with this system is most commonly used in Sanger Sequencing and PCR amplification. Details Specifications Features Specifications Main Functions Isolation up to 20µg plasmid DNA from 1-3ml bacterial culture Applications Enzyme digestion, sequencing, PCR and labeling,  etc. Purification technology Magnetic beads technology Process method Manual or automatic Sample type Conventional plasmid, plasmid≤30KB Sample amount 1-3ml Elution volume ≥50μl Principle This product is based on the purification method of high binding magnetic particles. The sample is lysed and digested under the action of lysate and Lysozyme. DNA is released into the lysate. After adding magnetic particles and binding solution, DNA will be adsorbed on the surface of magnetic particles, and impurities such as proteins will be removed without adsorption. The adsorbed particles were washed with washing solution to remove proteins and impurities, washed with ethanol to remove salts, and finally DNA was eluted by Elution Buffer. Advantages High purity – purified plasmid can be directly used in sequencing, enzyme digestion and PCR, etc. High yield – up to 20μg plasmid can be binded in one column Kit Contents Contents P181102 P181103 P181104 Purification Times 100 Preps 500 Preps 5000 Preps RNase A 10 mg 50 mg 2 x 250 mg Buffer P1 30 ml 150 ml 2 x 750 ml Buffer P2 30 ml 150 ml 2 x 750 ml Buffer N3 30 ml 150 ml 2 x 750 ml Buffer PW1 35 ml 180 ml 2 x 900 ml MagPure Particle NB* 2.2 ml 11 ml 2 x 60 ml Storage and Stability RNase A and MagPure Particle NB should be stored at 2-8°C upon arrival. However, short-term storage (up to 24 weeks) at room temperature (15-25°C) does not affect its performance. The remaining kit components can be stored dry at room temperature (15-25°C) and are stable for at least 18 months under these conditions. After addition of RNase A, Buffer P1 is stable for 6 months when stored at 2-8°C. Experiment Data
